Post pics of your enginebay fest


Found some pics of the old motor from my 85 T-Type.

I can't find any pics of it installed for some reason...

Was a stock 86 block with steel mains, forged pistons, lightly modded heads, small cam.
The intake was done by a guy in FL and used a stock intercooler with necks cut off it was gutted and completely redone. I was using a TA-54 on this combo. I don't remember where the headers/upipe came from (ATR?)

The car ran crappy ET's due to an open rear end but did a best MPH of 123 at ~22-23# of boost.

P5130004.JPG P5130005.JPG

This was in the car a while till I decided to swap to a 86/7 setup.

Almost finished, going for the clean look. Need to shine up the fender wells and put some loom on the braided lines. Has come a long way though.

Old setup:

ImageUploadedByTurboBuick Mobile1432746134.013572.jpg



New setup:

ImageUploadedByTurboBuick Mobile1432741068.436015.jpg


ImageUploadedByTurboBuick Mobile1432741079.461292.jpg





Posted from the TurboBuick.Com mobile app

Painted the inner fender wells, wipers back on, covered the rest of the braided lines with loom.

ImageUploadedByTurboBuick Mobile1433177982.432065.jpg


ImageUploadedByTurboBuick Mobile1433177993.006794.jpg


ImageUploadedByTurboBuick Mobile1433178002.362097.jpg



Posted from the TurboBuick.Com mobile app

The first pic is when i had got it and the rest is after a good cleaning and relocating the Charcoal Canister... I think it looks so much better!


Attachments

  • 2014-07 Tulsa 3.jpg
    2014-07 Tulsa 3.jpg
    72.6 KB · Views: 311
  • 2015-01-17 13.jpg
    2015-01-17 13.jpg
    2.7 MB · Views: 309
  • 2015-01-17 14.jpg
    2015-01-17 14.jpg
    2.2 MB · Views: 298
  • 2015-01-17 15.jpg
    2015-01-17 15.jpg
    2.3 MB · Views: 326
Final touch was changing my red spark plugs wires to black. Pretty much all black and white now under the hood.

Had no underhood light before so put some LED strip lights on the hood. Lights it up ridiculous now at night now.




LED hood light.jpg


Mine before I pulled it. Will go back in with 3.5 ext. gate DP and a few.....refinements
