Looking for injector clips

[dokovski_racing05]

In search of the clips that hold the plug for the injectors in place, making the plug not able to come off the injector.



[dokovski_racing05]

In search of the clips that hold the plug for the injectors in place, making the plug not able to come off the injector.



[TurboTGuy]

@ChuckLeeper might have some laying around



[N2BUICK]

I found 5, there maybe more.



[Anthony P]

retainers for the electrical terminal are not sold separately. your electrical connector with its hook shaped retainer clip is a little different than the commonly seen wire retainer designs for EV1.

Summit has plenty of kits with and without wiring pigtails. If the Casper's product 108112 will work for you - buy it direct from Caspers. links below.

Free Shipping on Orders Over $109 at Summit Racing

Find Parts and Accessories fuel injector ev1 wiring connectors KEYWORD and get Free Shipping on Orders Over $109 at Summit Racing!

www.summitracing.com

CASPER'S ELECTRONICS, INC.

Casper's Electronics, Inc

www.casperselectronics.com



[N2BUICK]

They are different from the stock injector clip. Mine won't help, Anthony to the rescue again.



[Anthony P]

They are different from the stock injector clip. Mine won't help...

Hi Austin, the clips (5) you showed secure the injector to the fuel rail.

The OP's pic shows he is missing these retaining clips.

It seems OP is pointing to the injector harness electrical terminal looking for same "U" shaped clip with hooked ends to retain such to the injector.

I'm not familiar with the hooked retaining clip as most use the Bosch EV1 connector having a "spring" wire retainer as shown below from Summit.

When the electrical connector clip is missing, suggest purchasing new EV1 connectors to re-work as needed or purchase a new harness from Caspers.



[Chuck Leeper]

I've seen a "few" of the original type.. Don't recall ever seeing the hook type.
